ES8C

Nominal size DN: 15, 20, 25, 32 ~ 50

Connection mode: internal thread, socket welding, flange
Nominal pressure PN: 50
Pressure difference range: MPa: 0.01 ~ 3.2
PMA/TMA PMa/℃ : 3.47/400
Shell material: WCB

Service Support Selection reference Hongfeng Classroom

Download ES8C

Features

1. Advanced SCCV closing system, spool bracket and specially designed "super lever" match. The spool is "free floating" in the spool bracket, avoiding rigid collisions when closed.

2. There is a water seal and lifting mechanism inside the bucket, so there is no steam leakage.

3. The top of the bucket is provided with an exhaust hole, which can effectively prevent the phenomenon of steam lock and air blockage (non-condensing high temperature air can also be excluded).

4.Can withstand high back pressure (up to 90%).

5. Water shock resistance.

6. All internals are fixed on the valve cover for easy online maintenance.

Uses: Used for medium and low pressure steam conveying, heat tracing pipeline and small steam equipment.
